Avionics Stack

The avionics stack houses the avionics sled and transmits recovery loads between the main and drogue shock cords. The outside components of the avionics stack assembly include the coupler, switchband, and two bulkhead assemblies. Attached to each bulkhead are wago levers, an u-bolt, charge wells, and a threaded rod with nuts. View the full animation to take a closer look at the internal components!
