Nesting Number Block

Designed and manufactured a parametric interlocking number block with Boss 3 and Pocket 4 features using Fusion 360 CAD/CAM workflows

Created engineering drawings, CAM toolpaths, and dimensional inspections while validating fit and manufacturability through PLA prototypes, machined POM test parts on a Tormach CNC mill, and final aluminum production

Number Block

Part_G3_FINAL

mesh_0

2.000 in

1.250 in

Applied dimensional offsets to the boss feature to resolve interference caused by tolerance stack-up during assembly validation

Boss 3

Applied positive tolerance offsets to accommodate maximum material condition (MMC) of mating components and ensure reliable interlocking fit
