Go Kart Blow Up

Took a few weeks to finalize.  Ran through 2 design review with coworkers.  Almost everything is parametric, so changes are easy to make.

Full Model

Part_0

mesh_0

Part_1

mesh_1

Part_2

mesh_2

Part_3

mesh_3

Part_4

mesh_4

Part_5

mesh_5

Part_6

mesh_6

Part_7

mesh_7

Part_8

mesh_8

Part_9

mesh_9

Part_10

mesh_10

Part_11

mesh_11

Part_12

mesh_12

Part_13

mesh_13

Part_14

mesh_14

Part_15

mesh_15

Part_16

mesh_16

Part_17

mesh_17

Part_18

mesh_18

Part_19

mesh_19

Part_20

mesh_20

Part_21

mesh_21

Part_22

mesh_22

Part_23

mesh_23

Part_24

mesh_24

Part_25

mesh_25

Part_26

mesh_26

Part_27

mesh_27

Part_28

mesh_28

Part_29

mesh_29

Part_30

mesh_30

Part_31

mesh_31

Part_32

mesh_32

Part_33

mesh_33

Part_34

mesh_34

Part_35

mesh_35

Part_36

mesh_36

Part_37

mesh_37

Part_38

mesh_38

Part_39

mesh_39

Part_40

mesh_40

Part_41

mesh_41

Part_42

mesh_42

Part_43

mesh_43

Part_44

mesh_44

Part_45

mesh_45

Part_46

mesh_46

Part_47

mesh_47

Part_48

mesh_48

Part_49

mesh_49

Four 350W electric scooter wheels power the go kart.  This gives very fast acceleration and excellent driving dynamics.

Drivetrain


Go Kart contains Caliper brakes which clasp the rear drivers side wheel.  More than enough for quick stops

Brakes

Go Kart contains two suspension elements.  Double wishbone in front and split frame in rear.  Front realistically does most of the work since rear coil overs are very stiff.

Suspension

Originally powered by Nema 17 steppers (pictured), I had to upgrade to a Nema 34 for additional power.  Steering rack is pulled from a 2015 Hyundai Sonata.

Steering

Entire front console is hinged and can lift out of the way to make room for driver.

Many additional buttons and a display are mounted here (not pictured)

Steering Bar

Wheel turns a Quadrature optical encoder.  This data is sent to a pi pico which commands the Nema 34 motor driver to step or switch direction.

Steering Wheel

The Go Kart contains additional Headlights, Taillights, High Beams, and of course Cup Holders.

All of these were one off CAD Projects I never implemented in the full scale model

Additional Features
