Problem Statement
The conventional manufacturing processes using assembly fixtures lack the precision required for manufacturing miniaturized ultrasound devices at high-volume production. This is required to fit inside a small catheter. Achieving the necessary +/- 15 micron accuracy for critical assembly steps, including UV adhesive dispensing, part alignment, and clamping, often relies on manual or semi-automated methods. These methods are prone to human error, time-consuming, and inconsistent, leading to increased scrap rates, higher production costs, and limitations in scaling manufacturing output. Therefore, there is a critical need for an automated solution that can consistently deliver ultra-high precision across multiple assembly stages to enable reliable and efficient manufacturing of these advanced miniaturized components.
Bill of Materials (BOM)
The following table lists the components used in the prototype, including part numbers, quantities, materials, estimated costs, and potential suppliers.
Item | Component | Part Number | Qty | Material | Cost ($) | Supplier | Notes |
1 | Heat Sink | 637-20ABPE | 1 | Aluminum | 25.00 | McMaster-Carr | 100x100x50 mm, extruded aluminum |
2 | Cooling Fan (12V, 40 mm) | AFB0412SHB | 1 | Plastic/Metal | 10.00 | DigiKey | Low-noise, 35 dB max, 12V DC |
3 | Device Housing | Custom (3D-printed) | 1 | PLA | 15.00 | University 3D Print Lab | FDM-printed, 200x150x100 mm |
4 | Thermal Insulation Foam | 851-074 | 0.5 m² | Polyurethane Foam | 8.00 | Amazon | Cut to fit optics compartment |
5 | Temperature Sensor | DS18B20 | 1 | N/A | 12.00 | Adafruit | ±0.5°C accuracy, digital output |
6 | Arduino Uno | A000066 | 1 | N/A | 25.00 | Arduino Store | Runs Python PID via serial interface |
7 | Fan Muffler | Custom (3D-printed) | 1 | PLA | 5.00 | University 3D Print Lab | Reduces fan noise |
8 | Fasteners (Screws, M3) | 91292A112 | 10 | Stainless Steel | 3.00 | McMaster-Carr | M3x10 mm, for securing components |
9 | Thermal Paste | AS5-3.5G | 1 | Silicone-based | 5.00 | Amazon | Improves heat transfer to sink |
Motor Review
Basic PID Controller Script
PYTHONimport time class PIDController: """A PID controller for precise control in robotic systems. Attributes: kp (float): Proportional gain. ki (float): Integral gain. kd (float): Derivative gain. setpoint (float): Desired target value. prev_error (float): Previous error for derivative calculation. integral (float): Accumulated integral term. dt (float): Time step in seconds. """ def __init__(self, kp: float, ki: float, kd: float, setpoint: float = 0.0): """Initialize PID controller with gains and setpoint. Args: kp: Proportional gain for error response. ki: Integral gain for accumulated error. kd: Derivative gain for error rate of change. setpoint: Desired target value (default: 0.0). """ self.kp = kp self.ki = ki self.kd = kd self.setpoint = setpoint self.prev_error = 0.0 self.integral = 0.0 self.dt = 0.01 def compute(self, current_value: float) -> float: """Compute PID output based on current system value. Args: current_value: Current measured value of the system. Returns: float: Control signal to adjust the system. """ # Calculate error error = self.setpoint - current_value # Proportional term p_term = self.kp * error # Integral term self.integral += error * self.dt i_term = self.ki * self.integral # Derivative term derivative = (error - self.prev_error) / self.dt d_term = self.kd * derivative # Calculate total output output = p_term + i_term + d_term # Update previous error self.prev_error = error return output if __name__ == "__main__": # Initialize PID controller pid = PIDController(kp=1.0, ki=0.1, kd=0.05, setpoint=10.0) # Simulate mode (e.g., motor position) current_value = 0.0 for _ in range(100): control_signal = pid.compute(current_value) # Simulate system response: position updates based on control signal current_value += control_signal * 0.1 print(f"Current Value: {current_value:.2f}, " f"Control Signal: {control_signal:.2f}") time.sleep(pid.dt)
