The top blocks were 3d printed, the bottom plate was laser cut. The left and right blocks and links were milled. Lastly, the brass rod and aluminum end cap were lathed.
Mini Car Jack
This was a project to familiarize me with our Mechanical Engineering Shop at Columbia. The goal was to fabricate a mini car jack using a mill, laser cutter, 3d printer, and lathe from engineering sketches.
Jason Mema
Project Timeline
Feb 2025 - Apr-2026
HighlightS
I was successfully able to fabricate the mini car jack. I gained a lot of experience with the lathe and mill, and this project was overall very fun!
SKILLS
Machining
3D Printing
Laser Cutting
Fabrication
